System Architecture

Comprehensive overview of DataProofLabs' distributed architecture, designed for scalability, security, and high-performance data processing.

High-Level Components

Various components interact seamlessly to provide a robust and scalable architecture.
High-Level Architecture Overview
System Overview

Enterprise Application Architecture

Any data processing system can be easily hooked into our architecture through well-defined APIs and integration points.
Data Flow & Processing Pipeline
Layered Application Architecture

Plug and Play Model

The proof logging is seperated from the application logic, allowing easy integration with existing systems via RESTful APIs or SDKs.
Security & Authentication Layer
Turn Key

Sample Architecture

You may have a microservices architecture built on any platform - our system can handle your blockchain data proofs seamlessly by hooking it up.
Microservices Architecture
Architecture and Technology Agnostic

Optimized

Optimize by rolling up. Can you imagine millions of data records under a $5 gas fee using our Merkle-based approach?

Example: One Arbitrum can support 500 transactions. Imagine 500 transactions per hour. With hourly logging, we need 750 to 2000 transactions a month. The total gas cost for this will come under just 4 Arbitrum — that is under $2 as of today's market price.

So your total cost, for a million monthly records, if you self-host the application on your own infrastructure, will be only $4 + monthly license fee + infrastructure. Or host with our preferred service providers.

The keys are stored on your own Secret Manager, Azure Vault, or AWS KMS. We never store your keys. You have full control of your keys and funds. Optionally, we can also manage the keys for you.

Infrastructure & Deployment
Infrastructure

Technology Stack

Frontend

React.js, TypeScript, Modern UI frameworks with responsive design and progressive web app capabilities.

Backend

Node.js, .NET Core, RESTful APIs, GraphQL endpoints with high-performance data processing.

Database

Distributed database systems, NoSQL solutions, caching layers, and real-time synchronization.

Infrastructure

Docker containers, Kubernetes orchestration, cloud services, and automated monitoring systems.
